With a servo motor, this packaging machine can achieve high filling accuracy, fast packing speed, and easy operation and adjustment. It is widely used in pharmaceutical, food, and daily chemical industries around the world, such as in the United States, Europe, Southeast Asia, and South Africa.
Message
Characteristics:
1. The machine is suitable for the food, medicine, chemical industry, and cosmetics industry of liquids, sauce of measurement packing.
2. All the work of bag making, measuring, filling, sealing, cutting and counting can be done automatically, at the same time, it can also according to the demand of customers printing batch numbers and other functions.
3. The touch screen operation, PLC control, drive stepper motor to control the bag length, stable performance, easy to adjust, and accurate detection. Choose the intelligent temperature controller and PID control to ensure the error range of temperature is controlled within 1 degree Centigrade.
4. Packing material： BOPP/Polyethylene, Aluminium/Polyethylene, Paper/Polyethylene, Polyester/Aluminizer/Polyethylene, Nylon/CPP, and so on.
Work Flow:
1. Premade Pouch Stack
2. Flip-Out Pouch-Picking Unit
3. Pouch Opening
4. Air Flushing
5. Filling I
6. Filling II
7. Pouch Stretching
8. Top Seal
9. Finished Product
10. Outlet
Technical Parameters:
| Model | Bag Size | Packing Speed | Measuring Scope | Total Power |
| HX-100 | 100 - 130 mm(L) 70 - 120 mm(W) | 10 - 45 bags/min | 1 - 15 g | 220V / 50-60Hz / 3.8kw |
